◊ Dear microburins,
Should this blog carry a safety message? ‘May contain burin spalls’? Meantime, Microburin is in north Northumberland on a commercial stint for a change. Be off with you, altruism!
◊ Dear microburins,
I’m normally a night owl but, having collapsed in bed with a couple of archaeology journals at 10pm last night, here I am awake in the early hours. So I thought I’d do something moderately useful before the sun rises and the day unfolds. This post offers notes on recent experiences in photographing lithic artefacts – efficiently and cost-effectively – in a manner suitable for assemblage characterisation reports (‘grey lit’ and HER¹/PAS²) and archiving. There’s a shopping list at the end and an outreach, as always, for feedback and advice.
¹ Historic Environment Record (HER) | ² Portable Antiquities Scheme (PAS). OASIS is a publicly accessible portal for submitting archaeological and fieldwork records to the relevant HER, with documents/images uploaded to Archaeology Data Service (ADS) digital archives.
Image | A bit of paraphernalia in the lithics lab for the blogtastic Day of Archaeology 2014.
A recent bout of lithics analysis needed some rapid, efficient and consistent images for the more significant pieces. The excavation-derived collection (not an assemblage per se) was in majority chert rather than flint – one of the fascinating aspects of prehistoric raw material consumption in north-east England related to availability in base and drift geology. The late glacial ice sheet dynamics and subsequent fluvial activity have created a jigsaw of knappable raw material types including limestone-derived cherts from the Pennines and various chalk-derived flint types from beds under the north sea, Scandinavia and farther south beyond the Yorkshire and Lincolnshire wolds. Flint remains readily available in east coast beach gravels, boulder clay deposits and some river gravels. Against this canvass, human mobility, most especially in the Mesolithic, provides for some interesting patterns in terms of what one finds where.
Images (below) | Top: Late Mesolithic flint microliths (narrow blade), Bottom: Side view of a Mesolithic chert core tablet.
I’m largely self-taught and results-driven when it comes to photographing lithics. I’ve experimented with black backgrounds and lighting configurations with some success. However, depth of field and pronounced shadowing for the more substantial artefacts have provided some challenges. Inevitably, a significant amount of work in image enhancement software is also needed, plus the addition of graphical scales (I use Corel because Adobe is too expensive). There can also be problems with darker coloured materials and especially the edges against a rather brutal black background. The results have been good, I think, but time-consuming. More on dark background specifications »
What I now find is far more efficient and consistent is using an acrylic frosted block, the type you see in museums or retail displays. In diffused natural daylight the block lets sufficient light permeate around the base of an artefact to suppress excessive shadows – the object almost seems to float in a milky ether – and allows for a small enough aperture (high f/stop number) to counter blurring within the frame, or between the top of an object and the scale, such as with deep objects like cores, items with heavy curvature or a deep arête. Lighting can be tuned by raising the block on a clear acrylic stand or placing foil or white card underneath – much cheaper than using a lightbox (not very transportable) or augmenting with artificial lighting. By using a good quality photographic scale I’ve also avoided the need to overlay digital scale images, although this is easy enough to do. And if an object needs support, I actually find that soft silicone earplugs (like bluetack but colourless) work fine.
Having a colour-correction scale has helped to maintain consistent hue/chroma results and I can, pretty much, adjust all images in a sequence using batch mode in photo/paintshop software, including corrections for barrel distortion (depends on your lens). The results feel good enough for archive/grey lit reports and need little extra work for publication-quality, as and when that becomes necessary. You can also combine objects, matched to scale, in a single merged image. You can’t really beat a good lithics line drawing but these remain open to the biases of interpretation – the eye of the penholder – and completeness in terms of what is included, excluded or emphasised. Drawing is subjective.
The beauty of this toolkit is that it can all be carried in a small plastic storage box and set up pretty much anywhere that’s suitably lit, perhaps excepting the lighting equipment which I keep in the lab. Office/fluorescent/tungsten lighting is challenging but can be neutralised/compensated for with camera settings (or manipulating raw file images).
So here’s the set-up I am operating. I’m absolutely open to advice and suggestions too. Supplier information is offered in good faith without any implied endorsement or coercion. It’s just good stuff, well-priced (although the camera and macro lens are relatively expensive – try second-hand if you don’t have one), and it works. I hope the following is pragmatic and useful:
The lithics selected for photography were photographed to display their dorsal and ventral faces, and additionally to give a side or platform view when required. Each image included a metric 50mm scale and true-colour correction panel. The lithic was placed on an opaque (frosted) acrylic display block and photographed in partially diffused natural light with the following equipment and settings:
I’ve not needed artificial lighting yet but assuming gloomy winter days:
Images were uploaded as JPEG files and colour-corrected using Corel PaintShop Pro X5 software against the true-colour panel (batch processing was cross checked). TIFF files are also appropriate and an accepted format for long-term archives. The images included in the written report are compressed at 220dpi resolution, the maximum permissible in Microsoft office applications³. Original unmodified JPEG images have been retained; RAW files were not generated due to their large file size and memory requirements although archive retention is recommended.
³ For MS Word or Powerpoint, go to File > Options > Advanced and click the “do not compress” box before saving to PDF or PDF-A (Archive).
Left: Late Mesolithic quadrangular (rhomboid) chert microlith, dorsal and ventral views | Right: Mesolithic chert core tablet, platform and base views.
After an exquisite summer of digging and fieldwork, I’m landed back at the surrogate home in London W10. Some recent personal events – not pleasant ones – are now likely to fast-track a series life-changing decisions, including committing to the Masters next year with a burning passion to continue Mesolithic research (I now have ten 14C dates for White Gill!), perhaps renting out the London home and moving to the soul’s home in Yorkshire and the north of England. I’ve given notice on the lithics lab too – now too expensive to retain, with enough done to be able to continue “in the sitting room” which doubles as my library and portal on inner-city London life. This has been also a juncture where relations with Lithoscapes Archaeological Research Foundation ended to allow me to focus on commercially viable work. I appreciate their good wishes and value the collaboration during my time there.
In the last week I have been making connections with archaeologists, heritage, museum and related professions on the “professional” social media app LinkedIn.
“I’ve been on LinkedIn, as one of the first million UK users, for over a decade now – it was launched in 2003. It has also been immensely useful in terms of professional visibility, networking, recruitment (both directions) and informed discussions. This is my personal experience and I am certainly not in a sales role here! In essence, people can find you. Doors open, without having to share pet stories, favourite foods, funny walks, or the other miscellany implicit in social media.” | Read more in my post »
I think I am also now in a position, after substantial recent experience, to apply to the Institute for Archaeologists (IfA, and now with a Royal Charter) at the appropriate level, referees required (and primed), peer reviewed and requiring a commitment to ongoing career development. In this sense, the Archaeology Skills Passport developed by David Connolly at BAJR is a key tool.
More news will follow, and thanks for following me in these volatile but positive times. Hey, the fieldwalking, supported by Solstice Heritage, on Teesside “came up with the money” – lowland Late Mesolithic-Early Neolithic lithics presence (we have Early Mesolithic adjacent too) around a micro-wetland area for which English Heritage’s Rapid Assessment Toolkit is also useful. Much to wash and write up with a prospect, thanks to impassioned landowners, for more work next year. PS, by kind permission we are using (and tuning) the excellent fieldwork recording sheets developed by Clive Waddington’s Archaeological Research Services.
Ongoing commitments as Chair of the feisty Teesside Archaeological Society mean that we are also trying to engage on local authority-approved (but not archaeologically supported) planning debacles on Teesside. You can review our engagements and, frankly, frustrations in being an Advocate of Heritage At Risk on our facebook page. Acklam Hall, Middlehaven and increasing Green over Brownfield developments need a community to care about their heritage when due process threatens destroying it.
And, in my final term as CBA Yorkshire’s Editor, I will be focusing on the third volume of FORUM YORKSHIRE – our annual journal – for the final call-for-papers by end of this calendar year. If you are doing archaeology in Yorkshire….you know where to publish.
Having finished digging at Kiplin Hall, a quick trip south, I’m back in Yorkshire and looking forward to meeting friends – new, old and social mediaries – on Saturday 23 August at the Flixton Island mesolithic party-in-the-peat open day, hopefully arriving around 9am. Sunday is an open day too. Details follow below »
Kiplin, where I was supervising and training volunteers with two lovely colleagues for three weeks, was a splendid, friendly HLF-funded project with fantastic archaeology that spanned several thousand years in finds: Mesolithic chert (and a microlith!) to 17th-century musket balls, WWII bullet cases and a 1964-dated pigeon ring which we can trace. I’ll write more in a future post.
A Mesolithic chert core tablet from Kiplin test pits.
Walk back 12,000 years to the end of the last Ice Age. See the latest excavations and finds, and quiz the expert archaeologists about life in the past.
Come along and learn about excavations of the Late Palaeolithic and Mesolithic sites from 12,000 to 11,000 years ago that once existed on an island in the now vanished Lake Flixton.
FREE site tours will take place on both days at 10.00am, 12.30pm and 3.30pm. Tours will last around 30 minutes.
On the Saturday, Tim Burkinshaw @CarrsWetland from The Carrs Wetland Project will lead tours at 11.00am and 1.30pm around the wetland landscape looking for clues to the shrinking peat and explaining how local farmers are helping to protect the heritage of the floodplain with its wildlife.
There will be opportunities to see some of the recent finds and talk to the experts about what they tell us about life at the end of the Ice Age.
Visit the bookstall where you can buy the small booklet (£2) or the illustrated book (£13) about the famous nearby site of Star Carr and the Mesolithic sites around Lake Flixton. All profits go towards further public events.
Artist Ruth Collett will be on site on Sunday afternoon to talk about her work interpreting the excavation in film and sculpture.
Travelling from York, take the A64 to Staxton, then take the A1039 towards Filey. When you get to the village of Flixton, take the left hand turn down Flixton Carr Lane (if you reach the Foxhound Pub, you’ve travelled too far through Flixton village). Parking is available in a nearby field. For safety reasons, please park there and take the short walk to the site rather than driving up to the site huts.
It’s Friday the 11th of July and the international Day of Archaeology! This is the day when hundreds of archaeologists around the world share their secrets, their pleasures and their work in a blog post (web diary). You can follow it on the website or on the Twitter with hashtag #dayofarch. Why wouldn’t you?
Is that a rod microlith in your ziplock or are you just happy to see me?
My own contribution requires you to observe the Captain’s illuminated seat belt sign, place your tray tables in the upright position and strap yourself in for some Mesolithic turbulence (sic) ahead. I hope you also enjoy the lithicist’s toolkit, clamps, slabs, scales, calipers (digital don’t you know), a protractor and a neat little USB x200 microscope. I also won £1.50 on the illustrated Lotto ticket and I shan’t be sharing.
♦ Mesolithic Spence
Extraordinary news from the Star Carr project team (University of York) is that part of the Vale of Pickering, containing Upper Palaeolithic and Mesolithic wetland archaeology, is on the market for £550,000 or as four lots* – see the links and image below.
*Lots 3 (£125,000, 25 acres) and 4 (£305,000, 61 acres) contain Flixton Island and No Name Hill respectively.
The pasture, under a short-term stewardship agreement, is the location of Flixton Island and No Name Hill which were indeed islands in the post-glacial palaeo-lake Flixton. This is a beautiful landscape and wildlife habitat sitting between the Yorkshire Wolds and North York Moors in an area where tourism is a major economic component. Recent excavations have proven organic preservation under surviving peat that includes a horse butchery site and several Early Mesolithic activity areas. As the project team point out, the risk is that the future owner or owners will not be sympathetic to this special archaeological resource and that, at the end of the stewardship cycle which brings in a modest annual income, agricultural practices may revert to arable, destructive activities. I do note that the archaeological assets are hardly mentioned in the PDF brochure and that only the nearby Star Carr is an archaeological scheduled area – and rapidly drying out.
Is there any hope that the partnership capabilities of charitable organisations, perhaps with sympathies from national and governmental bodies, might come together in order to purchase the land and secure it for the broader public? The Vale of Pickering is a rich natural (if managed) resource as evangelised by the likes of the Carrs Wetland Project. £550,000 is a modest sum in terms of Heritage Lottery and land management initiatives that receive support. Indeed, compare with the considerable sums raised to rescue treasure trove finds in recent years and the success of crowd-sourcing projects that enable public access to heritage, nature and learning. The Crosby Garret Roman parade helmet sold, regrettably, to a private bidder for £2.3M and yet the Tullie House Museum was able to raise £1.7M in an attempt to secure it. £0.55M seems less daunting?
Would the very special habitat – and its development as a public asset – not garner the interest of the National Trust and RSPB? After all, they also bring the relevant land management expertise and oversight to conserve complex living landscapes? Is a campaign out of the question?
There is already a Vale of Pickering Trust that supports the archaeological ventures and has done so for many years – so is the coordination vehicle already there?
If only I had the savings, I’d jump at this in a second: more lottery tickets I guess!
Just published today by Natural England, a new report demonstrates the value for money delivered by investing in the natural environment – wetland habitats being an important one – including carbon storage, resilience to climate change, health and well-being, and attractiveness to future investment, tourism and recreation.
“The Monitor of Engagement with the Natural Environment survey demonstrates that in 2012-13, 2.85 billion visits were made to the natural environment with expenditure totalling from £17.6 – £24.5 billion.”
